Banda Beat 800.4

$1,600.00

Compare
SKU: BEAT 800.4 Categories: , Brands:

Description

PARAMETER
BEAT 800.4 – BRIDGE 2 OHMS
BEAT 800.4 – BRIDGE 4 OHMS
Total Power 14,4 @ 1 Ohm
4 x 200 WRMS
Total Power 14,4 @ 2 Ohms
4 x 140 WRMS
4 x 200 WRMS
Total Power 14,4 @ 4 Ohms
4 x 140 WRMS
Total Power 14,4 Bridged @ 2-4 Ohms
2 x 400 WRMS (2 Ohms)
2 x 400 WRMS (4 Ohms)
Efficiency @ 4 Ohms
85%
Efficiency @ 2 Ohms
84%
82%
Efficiency @ 1 Ohm
75%
Input Voltage
9 – 15V
9 – 15V
Input Impedance
22K Ohms
22K Ohms
THD+Noise
0,10%
0,10%
Input Sensitivity
250mV – 1,4V
250mV – 1,4V
SNR
95dB
95dB
Frequency Response (Key OFF)
Frequency Response
10 to 25kHz (-3dBs)
10 to 25kHz (-3dBs)
HPF (High Pass Filter)
80Hz @ 12dB/octave Linkwitz-Riley
80Hz @ 12dB/octave Linkwitz-Riley
LPF (Low Pass Filter)
80Hz @ 12dB/octave Linkwitz-Riley
80Hz @ 12dB/octave Linkwitz-Riley
Recommended Fuse
40 A
40 A
Current at Rest
1,0 A
1,0 A
Average Current Draw (Sinusoidal)
80 A
80 A
Average Current Draw (Music)
40 A
40 A
Power Wire Gauge (min. Recommended)
10mm / 7 AWG
10mm / 7 AWG
Speaker Wire Gauge (min. Recommended)
2 x 1,5mm / 2 x 16 AWG
2 x 1,5mm / 2 x 16 AWG
Weight (Lb)
2,5
2,5
Height (in)
1,6
1,6
Width (in)
5,5
5,5
Depth (in)
7,2
7,2
