Total Power 14,4 @ 1 Ohm |
2600 WRMS |
Total Power 14,4 @ 2 Ohms |
2000 WRMS |
Total Power 12,6 @ 1 Ohm |
2000 WRMS |
Total Power 12,6 @ 2 Ohms |
1400 WRMS |
Efficiency @ 2 Ohms |
77% |
Efficiency @ 1 Ohm |
65% |
Input Voltage |
9 – 15V |
Input Impedance |
100K Ohms |
THD+Noise |
<1% |
Input Sensitivity |
160mV – 4V |
SNR |
70dB |
Frequency Response (Key OFF) |
5 to 22kHz (-3dBs) |
Frequency Response |
20 to 20kHz (-3dBs) |
Bass Bosst @ 45Hz |
Variable 0 to +18dBs |
HPF (Subsonic) |
20 to 80Hz @ 12dB/octave Linkwitz-Riley |
LPF (Crossover) |
80 to 20kHz @ 12dB/octave Linkwitz-Riley |
Recommended Fuse |
100 A |
Current at Rest |
2 A |
Average Current Draw (Sinusoidal) |
220 A |
Average Current Draw (Music) |
110 A |
Power Wire Gauge (min. Recommended) |
21mm / 4 AWG |
Speaker Wire Gauge (min. Recommended) |
2 x 4mm / 2 x 11 AWG |
Weight (Lb) |
7,2 |
Height (in) |
2,2 |
Width (in) |
8,4 |
Depth (in) |
9,7 |
