FT200 High Performance AGM Battery
| Weight | 13.23 lbs |
|---|---|
| Dimensions | 6.69 × 3.9 × 6.18 in |
| Weight (kg) | 6.0 kg |
| Dimensions (mm) | 170 x 99 x 157 mm |
| Group Size | BTX20L-BS |
| Voltage | 12-Volt |
| Terminal Type | M6M |
| CCA | 200 |
| CA or MCA | 265 |
| HCA | 300 |
| PHCA | 535 |
| Capacity @ 20hr Rate | 14 |
| Reserve Capacity @ 25 Amps | 20 |
| Reserve Capacity @ 75 Amps | – |
| Watts | 550 |
| Internal Resistance | 12.3 mΩ |
